F-14A Cutaway Drawing





Graphic Copyright © Grumman via Koku-Fan No.89, 1977
Click here for a larger version.

1. Radar tuning horn 2. Planar-array radar scanner
3. Inertial navigation system 4. ADF sense aerial
5. Windscreen rain dispersal air ducts 6. Pilot's instrument console
7. Ejection seat 8. RIO's instrument console
9. Pilot's rear view mirrors 10. Glass canopy
11. Glove vane 12. Flight control rod linkage
13. Wing box 14. Wing sweep actuating screw jack
15. Wing box integral fuel tank 16. Main fuselage frame
17. Jet engine 18. Wing glove sealing plate
19. Aft fuselage fuel tank 20. Speedbrake
21. Rudder hydraulic actuator 22. Engine nozzle
23. Horizontal stabilizer rib 24. Nozzle actuator
25. Tailplane hydraulic actuator 26. Main frame
27. Hydraulic reservoir 28. Engine accessory equipment gearbox
29. Flap drive shaft 30. Spoiler hydraulic actuators
31. Wing pivot bearing 32. Forward fuselage fuel tank
33. Intake ramp hydraulic actuator 34. Glove vane hydraulic actuator
35. Air data computer 36. Avionics equipment bay
37. Electrical relay panel 38. Canopy jack
39. Electrical system equipment 40. Ammunition drum
41. Boarding ladder 42. M61-A1 cannon
43. Formation lighting strips 44. Radar equipment bay
